NSYPLA15103G

Range

Thalassa

Product name

Thalassa PLA

Enclosure type

Multi-purpose

Product or component type

Suitable enclosure

Version

PLA

Nominal height

1500 mm

Nominal width

1000 mm

Nominal depth

320 mm

Enclosure mounting

Floor-standing

Device composition

1 top part 1 bottom part 2 side part 2 door 2 rear panel

body type

Sealed top and bottom part assembled with side parts

Door type

Plain front

Number of doors

2 door(s)

Door opening side

Right and left (120 °)

Lock type

4 points lock, 5 mm double-bar

accessibility for operation

Rear Front

Removable parts

Door by hinges Rear panel by fixing element

Material

Polyester reinforced with fibreglass

Colour

Grey (RAL 7035)

standards

UL 508 A IEC 62208

NEMA degree of protection

NEMA 12 NEMA 13 NEMA 2 NEMA 1

product certifications

DNV Marine UL/cUL listed Veritas

Electrical insulation class

Class II

IP degree of protection

IP65 conforming to IEC 60529 (completely sealed)

IK degree of protection

IK10 conforming to IEC 62262 (plain door)

Fire resistance

960 °C conforming to IEC 62208

Ambient air temperature for storage

-35…90 °C

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

152.0 cm

Package 1 Width

103.0 cm

Package 1 Length

38.0 cm

Package 1 Weight

58.651 kg

Warranty

18 months
